The research work mainly uses molecular design and crystal engineering to realize the controlled growth of organic semiconductor crystals. From the preparation of large-size, high-purity and low-cost organic single crystals to the controlled growth of ultra-thin and two-dimensional organic single crystals and organic eutectic, a series of studies have been carried out to realize the regulation of the proportion, dimension, size and charge transfer degree of organic crystals. The problems of effective charge transport and precise control of non-covalent bond interaction are overcome, and the construction and application of high performance organic single crystal FET are realized.

1. It breaks through the difficult problem of preparing large size and high purity organic semiconductor crystal materials

2. A method of controlled growth of organic semiconductor crystals has been developed, and the proportion, size, dimension and charge transfer degree of the crystals have been regulated

3. The crystal growth mechanism of organic semiconductor materials was investigated

4. Combined with the molecular structure characteristics, the application of organic crystal materials in photoelectric and energy devices is expanded

5. Realization of large size organic semiconductor doped crystals in the field of X-ray imaging

Representative paper:

Crystal Growth & Design. http://dx.doi.org/10.1021/acs.cgd.4c00251

ACS Applied Electronic Materials. http://dx.doi.org/10.1021/acsaelm.4c00328
